This tractor is intended for various agricultural operations coupled with mounted, semi-mounted and trailed machines, for hauling operations and for operations in industry.
Small dimensions allow using the tractor in greenhouses and small rooms, low-contour land plots.
Environmental standard Stage IIIa.
Model : «LOMBARDINI» LDW2204T
Power, kW (h.p.) : 46 (62,5)
| Engine | |
|---|---|
| Type | Four-stoke turbocharged diesel engine with pre-chamber injection |
| Model | «LOMBARDINI» LDW2204T |
| Power, kW (h.p.) | 46 (62,5) |
| Crankshaft rated speed, rpm | 3000 |
| Number of cylinders, pcs. | 4 |
| Displacement, l | 2, 07 |
| Maximum torque, Nm | 174 |
| Specific fuel consumption at operating power, g/kWh | 329 |
| Factor of torque backup, % | 18 |
| Fuel tank capacity, l | 90 |
| Transmission | |
| Clutch | Dry, single-disk |
| Gearbox | Mechanical, with easy-engagement clutches |
| Number of gears: forward/reverse | 16/8 |
| Travel speed: forward/reverse, km/h | 1,2-36,6/2,1-19,5 |
| Rear PTO: | |
| Continuous I, rpm | 540 |
| Continuous II, rpm | 1000 |
| Ground-speed I, rev/m of travel | 3, 2 |
| Ground-speed II, rev/m of travel | 6 |
| Hydraulic Lift Linkage | |
| Versatile, remote-cylinder | |
| Lifting capacity at suspension point, kg | 2800 |
| Maximum pressure, MPa | 20 |
| Pump performance,l/min | 40 |
| Hydraulic system capacity, l | 22 |
| Dimensions And Weight | |
| Overall length, mm | 3450 |
| Width, mm | 1700 |
| Height to cabin top, mm | 2380 |
| Tractor base, mm | 1390 |
| Track, mm: | |
| Front Wheels | 1390, 1530 |
| Rear Wheels | 1410, 1510, 1560, 1660, 1730 ,1830 |
| Agrotechnical clearance, mm | 560 |
| Least turning radius, m | 3, 9 |
| Operating weight, kg | 4000 |
| Tire sizes: | |
| Front Wheels | 12, 4R-16 |
| Rear Wheels | 360/70R24 |
| Wheel Arrangement | 4Ñ…4 |
